Features and benefits:
Features
Plate pair pattern: Dimple, studded flat
Design pressure: Vacuum ～ 3.5MPa
Plate thickness: 1.0 ～ 2.5mm
Design Temp.: ≤350℃
Channel gap: 8 ～ 30mm
Max. surface area: 2000m2
Structure of plate pack
The channel at one side is formed by spot-welded contact points that between dimple-corrugated plates. Cleaner medium runs in this channel. The channel at the other side is wide gap channel formed between dimple-corrugated plates with no contact points, and high viscous medium or medium containing coarse particles runs in this channel.
The channel at one side is formed by spot-welded contact points that are connected between dimple-corrugated plate and flat plate. Cleaner medium runs in this channel. The channel at the other side is formed between dimple-corrugated plate and flat plate with wide gap and no contact point. The medium containing coarse particles or high viscous medium runs in this channel.
The channel at one side is formed between flat plate and flat plate that welded together with studs. The channel at the other side is formed between flat plates with wide gap, no contact point. Both channels are suitable for high viscous medium or medium containing coarse particles and fiber.
